Key Features

• High-Capacity Storage: Available in 2000 US Gallons and 5000 US Gallons models
• DNV Certification: Ensures compliance with international maritime standards
• PESO Approval: Meets Indian regulatory requirements for pressure vessels
• State-of-the-Art Insulation: Double wall vacuum with multi-layered super-insulation for minimal heat transfer
• Robust Construction: Designed for durability and long-term performance
• Pressure Build-Up Units: Integrated systems for efficient pressure management
• Flexible Applications: Suitable for storage, transportation, and on-site usage

Technical Specifications

2000 US Gallons LN2 Tank

• Gross Capacity: 7,570 liters (2,000 US gallons)
• Net Capacity: 7,190 liters (1,900 US gallons)
• Working Pressure: 1.70 MPa (246.5 psig)
• Design Temperature Range: -196°C to +38°C (-320°F to +100°F)
• Inner Vessel Material: SA-240M 304 stainless steel
• Outer Vessel Material: SA-36 carbon steel (heads), A1011 carbon steel (shell)
• Insulation: Vacuum with multi-layer super insulation
• Tare Weight: Approximately 5,900 kg (13,005 lbs)
• Maximum Gross Weight: 18,000 kg (39,679 lbs)
• Overall Dimensions: 2,991 mm (L) x 2,438 mm (W) x 2,591 mm (H)
• Evaporation Rate: Approximately 0.42% per day (for nitrogen)

5000 US Gallons LN2 Tank

• Gross Capacity: 18,927 liters (5,000 US gallons)
• Net Capacity: Approximately 17,980 liters (4,750 US gallons)
• Working Pressure: 1.60 MPa (232 psig)
• Design Temperature Range: -196°C to +50°C (-320.8°F to +122°F)
• Inner Vessel Material: SA-240M 304 stainless steel
• Outer Vessel Material: SA-36 carbon steel or SS304 stainless steel
• Insulation: Vacuum with multi-layer super insulation
• Tare Weight: Approximately 12,200 kg (26,896 lbs)
• Maximum Gross Weight: 34,000 kg (74,957 lbs)
• Overall Dimensions: 12,192 mm (L) x 2,438 mm (W) x 2,591 mm (H)
• Evaporation Rate: Approximately 0.22% per day (for nitrogen)

Compliance and Certifications

• ASME VIII DIV 1
• LR
• PESO (Petroleum and Explosives Safety Organisation) Approval

Applications

• Industrial gas supply chain
• Cryogenic storage facilities
• Oil and gas well activation

Safety Features

• Pressure relief valves
• Vacuum-insulated design
• Robust piping and valve systems
• Level indicators and pressure gauges
