Well Services Solution presents our innovative Lightweight 2 Phase Separator, designed for offshore platforms and remote locations where space and weight constraints are critical. This cutting-edge separator offers high-efficiency separation of multiphase flows, combining compact design with advanced measurement capabilities.

Key Features

• High-Efficiency Inlet Deflector: Ensures optimal separation of gas and liquid phases.
• Mist Extractor: Minimizes liquid carryover into the gas outlet.
• Advanced Flow Meters: Equipped with high-accuracy Coriolis Meters for precise measurement of oil and gas flows.
• Optional Water Cut Meter: Provides real-time water cut measurement with exceptional accuracy.
• Compact and Lightweight Design: Ideal for offshore applications and remote locations.
• Skid-Mounted Unit: Supplied on a DNV Type Approval skid for easy handling and installation.

Technical Specifications

• Gas Flow Capacity: Up to 8 MMSCFD
• Liquid Flow Capacity: Up to 5000 BLPD
• Operating Pressure: 50 psig to 2160 psig
• Operating Temperature: Up to 100°C (212°F)
• Measurement Accuracy:
  • Coriolis Meter: ±0.1% to ±0.35% for gas and liquid measurement
  • Water Cut Meter: ±0.2% to ±0.5% for water cut measurement

Applications

• Well testing
• Production facilities
• Early production systems
• Offshore platforms
• Remote onshore locations

Design Standards

• API 12J: Specification for Oil and Gas Separators
• API 14E: Recommended Practice for Design and Installation of Offshore Production Platform Piping Systems
• ASME B31.3: Process Piping
• ASME Section VIII, Division 1: Rules for Construction of Pressure Vessels
• DNV 2.7.1

Enhanced Safety and Maintenance

• Bypass Provision: Ensures uninterrupted operations during maintenance.
• Inline Pilot-Operated Pressure Safety Valve (PSV): Protects against overpressure conditions.
• Easy Maintenance: Designed for minimal human intervention, reducing downtime.
• Simple Calibration: User-friendly meters and instruments for accurate performance.

Well Services Solution's Lightweight 2 Phase Separator represents the pinnacle of separation technology for challenging environments. Its compact design, coupled with high-precision measurement capabilities, makes it the ideal choice for offshore platforms and remote locations where every inch and pound matters
