Pressure Testing Skids

• Pressure Range: 0 - 25,000 psi (0 - 1,724 bar), customizable
• Flow Rate: Up to 100 GPM (378 LPM)
• Power Options: Diesel hydraulic, electric, or pneumatic drives
• Safety Features: Redundant pressure relief valves, automated emergency shutdown systems

Chemical Injection Skids

• Injection Pressure: Up to 15,000 psi (1,034 bar)
• Flow Rate Range: 0.1 - 100 GPH (0.38 - 378 LPH) per pump
• Chemical Dosing Accuracy: ±0.5% across flow range
• Tank Capacity: Customizable from 100 to 10,000 gallons (378 to 37,854 liters)
• Materials: 316L Stainless Steel, Duplex, Super Duplex options
• Hazardous Area Classification: ATEX Zone 1, Class I Div 1 compliance
• Control System: PLC-based with HMI interface, SCADA integration

Common Features

• Modular design for easy transportation and installation
• Customizable to meet specific operational requirements
• Compliant with API, ASME, NACE, and other industry standards
• Rugged construction for harsh environments
• Integrated automation for seamless field integration
• Comprehensive documentation and material traceability

These specifications highlight WSS's commitment to providing high-performance, safety-compliant, and versatile solutions for critical oilfield operations.
