Dual Pot Sand Filter: High-Pressure Solids Removal Solution

The Dual Pot Sand Filter is an essential piece of equipment designed for efficient sand and solids removal from well fluids and gas in oilfield operations. Our advanced system offers superior performance for a wide range of onshore and offshore applications, including well clean-up, flowback, surface well testing, and early production.

Key Features

• • High-Pressure Rating: Engineered to withstand pressures up to 15,000 psi, suitable for demanding well conditions.
• • Versatile Filtration: Available with 100, 200, and 400 micron screens to handle various particle sizes.
• • Dual Pot Design: Allows for continuous operation by diverting flow between pot A and pot B, with bypass capability.
• • Easy Maintenance: Designed for quick and efficient cleaning of sand screens.

Advanced Design

• • Dual isolation gate valves for reliable flow control
• • Pressure and differential pressure gauges for accurate monitoring
• • Water jetting system for effective cleaning
• • Hammer unions for convenient piping connections
• • Robust steel structure for easy transportation and operation

Performance

• • Handles high gas flow rates up to 50 MMscf/d (15,000 psi model)
• • Liquid flow capacity up to 10,000 Bpd
• • Achieves up to 99% solid processing efficiency at high flow rates

Included Accessories

• • Torque gun for precise valve operation
• • Karcher high-pressure water jetting pump for thorough cleaning
• • Overhead chain pulley for safe and efficient handling of components

Applications

• • Well clean-up operations
• • Flowback processes
• • Surface well testing
• • Early production stages

Compliance and Standards

Our Dual Pot Sand Filters are designed and manufactured in accordance with:

• • API 6A
• • ASME VIII DIV 2
• • ASME B31.3
• • NACE MR 0175 / ISO 15156

With its robust construction, high-pressure rating, and user-friendly design, our Dual Pot Sand Filter offers a reliable and efficient solution for sand and solids removal in challenging oilfield environments. The system's flexibility and ease of maintenance make it an ideal choice for operators seeking to protect downstream equipment and optimize production processes.
